Overview
The SONSILL 219mm Hollow WPC Wall Cladding is a lightweight exterior wall siding board engineered for commercial building facades, boundary walls, construction site hoardings, and outdoor wall applications where cost-effective coverage, ease of handling, and adequate outdoor durability are the primary specification requirements. The hollow-core WPC profile reduces material weight to 2.85 kg/sqm while maintaining sufficient structural rigidity for standard exterior wall cladding applications. At 219mm wide and 26mm thick, each 2900mm-length board provides efficient facade coverage and installs onto a standard aluminium or timber batten subframe using screw-fix or clip systems. The WPC composite construction provides resistance to moisture, rot, and insects, and low water absorption suitable for outdoor siding in standard climate conditions. Designed for building contractors, commercial fit-out teams, and wholesale distributors supplying cost-effective exterior wall cladding solutions for commercial and light industrial projects.
Specifications
- Material: WPC Hollow Core
- Width: 219mm
- Length: 2900mm
- Thickness: 26mm
- Profile: Hollow
- Coverage per Board: 0.635 sqm
- Weight: 2.85 kg/sqm
- Water Absorption: ≤0.8%
- Formaldehyde Emission: E0 (Eco-Friendly)
- Fire Rating: Class B1 (Fire Retardant)
- Service Life: 20+ Years
- MOQ: 500 meters
- Origin: China
- Certification: CE, SGS
Applications
- Commercial building exterior wall siding
- Garden boundary and perimeter wall cladding
- Construction site hoarding and temporary facade panels
- Light industrial building exterior wall cladding
- Outdoor courtyard and terrace wall panels
- Low-rise residential exterior wall siding
Features
- Hollow-core profile — significantly lighter than solid WPC at 2.85 kg/sqm for easier handling and installation
- 219mm wide board format — efficient facade coverage with fewer boards per sqm
- Cost-effective exterior cladding solution — suitable for large-area commercial and boundary wall applications
- Water absorption ≤0.8% — adequate moisture resistance for standard outdoor siding applications
- Resistant to rot, insects, and mold — low-maintenance alternative to timber siding
- 20+ year service life in standard outdoor conditions
- E0 formaldehyde-free composite — environmentally responsible material specification
- Class B1 fire retardant rating meets commercial building code requirements
- Compatible with standard aluminium and timber batten subframe systems
Installation
SONSILL 219mm Hollow WPC Wall Cladding boards install horizontally onto a prepared aluminium or timber batten subframe using face-fix stainless steel screws or a compatible clip system. Erect the subframe at 400–600mm centres, ensuring all members are level, plumb, and structurally fixed to the building substrate. For screw-fix installation, pre-drill pilot holes through the hollow board face at each batten location to prevent board splitting. Fix boards sequentially from the base of the wall upward, maintaining consistent joint spacing. Maintain a minimum 10mm expansion gap at all board ends and perimeter junctions to accommodate thermal movement. Note that the hollow-core profile is not suitable for applications requiring cut-end exposure — finish all exposed board ends with compatible SONSILL WPC end caps or aluminium trim sections. Contact SONSILL technical support for large-scale commercial or boundary wall project installation specifications.
FAQ
Is this panel for outdoor use?
This SKU is listed in the outdoor WPC wall cladding range. Confirm profile type, co-extrusion status and climate zone before exterior installation.
Can I request samples before a bulk order?
Yes. Share climate zone, color direction and quantity so we can align samples, packing and quote details.
